Maglumi 800
Chemiluminescense Immunoassay (CLIA) System
Click Here To See the Product Brochure
| Parameter |
Typical Specification |
| Reagent Feature |
- Flash chemiluminescence label –ABEI, with high sensitivity and long stability
- Nano magnetic microbeads separation, fast and efficient
|
| Main Features |
- Throughput: up to 180 tests/hour
- 24 hours ready-to-use
- Time to first result: 17 minutes
|
| Modes of Operation |
|
| Sample Loading |
- Up to 40 samples tubes
- Continuous loading, STAT available
- Barcode reader recognition or analyzer auto numbered
- LIS connection, auto read sample info
- Refrigerated sample area with independent power supply
|
| Reagent Loading |
- 9 reagents on board
- Continuous loading
- RFID reading all info of reagent
- Refrigerated reagent area
|
| Reagent Integral |
- Ready-to-use, no pretreatment required
- Including calibrators
- RFID tag storing all info of reagent
- RFID tag with built-in master curve
- 2-point calibration to adjust master curve
- Calibration stability: Max 4 weeks
|
| Other Features |
- Clot detection
- Liquid level detection
- Auto and optional ratio for high sample dilution
- Constant 37°C incubation
|
| Operation System |
- Windows 7
- HP compatible (Dual-core CPU)
- Color touch screen
|
| Interconnection |
- Bi-communication with LIS via ASTM protocol
|
| Dimensions Weight |
- Input: AC 110-230V, 50/60HZ, Max 630W
- Dimension and weight: 102 x 72 x 56cm 73kg
|
